PM 47-Ton Knuckle Boom Crane

The PM 47-ton knuckle boom (articulating) crane is part of PM’s truck-mounted crane range. This page is a model reference for specs and documentation, plus parts and service for this model. PM articulating cranes are comparable to Fassi, Cormach, Hiab, Palfinger, Atlas, Amco Veba, Heila and IMT cranes.

Available 47-ton configurations, with maximum lift and maximum reach for each model:

• Model 47022 P — max lift 13007, max reach 25’5
• Model 47023 P — max lift 9811, max reach 32’6
• Model 47024 P — max lift 7606, max reach 39’6
• Model 47025 P — max lift 5842, max reach 47’1
• Model 47026 P — max lift 4719, max reach 54’8
• Model 47024 P + J92 — max lift 3307, max reach 60’0
• Model 47024 P + J93 — max lift 2315, max reach 66’3
• Model 47024 P + J94L — max lift 1764, max reach 72’6
• Model 47025 P + J92 — max lift 2138, max reach 67’3
• Model 47025 P + J93 — max lift 1433, max reach 73’6
• Model 47025 P + J94L — max lift 992, max reach 79’9

Download the 47-ton crane brochure: 47_Ton_PM_Articulating_Crane_Brochure_english.pdf, 47_Ton_Knuckleboom_Brochure_metric.pdf.

Parts for this crane

We stock and ship parts and service items for this PM knuckle boom crane model, including cylinder seal kits and seals, sliding blocks and wear pads, Scanreco radio remote parts, and hydraulic fittings, hoses, valves and filters. Browse the full PM crane parts catalog, or call (877) 697-6272 with your model and serial number and we will match the exact part for your crane.
